Environmentally friendly R290 hydrocarbon refrigerant
Cabinet and doors are insulated with 2” CFC free, foamed in place polyurethane
Exclusive “stepped” door design to protect door gasket
Spring assisted self-closing doors with stay open feature
Extruded aluminum flush mount door handle
Field reversible doors with magnetic snap-in gaskets
Magnetic door gasket is easily removable for cleaning
Removable air filter for easy cleaning
Hot gas condensate removal
Mullion heaters for reduced condensation
E-coated evaporator coil
Digital temperature display
Two epoxy coated shelves per section is standard
Anodized aluminum shelf supports adjustable in 1/2” increments
Shelves hold a full- size sheet pan and 120 lbs. capacity
Standard with 6” casters (three with brakes)
10 ft. cord and plug
Electrical Specs
Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 1.87 kwh/day, Amperage: 5, Max Fuse/HACR Breaker: 15 A
Operating Limits
Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 28 – 45°F, Refrigerant: R290
Refrigeration Data
Nominal Compres. of 2431 BTU/hr at 1/3 HP, Heat Rejection: 448 BTU/hr
Storage Specifications
Nominal storage capacity: 30.17 ft3, Interior storage capacity: 30.17 ft3, Door opening: 22.5″ W x 23″ H, Depth with door fully extended: 57.75″ D, Shelves included: 6
